SMC Type AL Aeris Lubricator

Pro artificio faciendo, OLK tibi praebere vellem SMC Type AL Air Lubricator. Et OLK (Ouleikai) tibi optimam post venditionem praestabit et opportunam traditionem.

Mitte Inquisitionem

depictio producti

SMC Typus AL Aeris Lubricator ab OLK fabricator pneumaticus fabricatus accuratam machinis amni lubricationem efficit. Alveus AL (magnitudines 30 et 40) protegitur a protectore pellucido, permittens observationem comprehensivam ab omnibus angulis. Distributio ducatus rate modificari potest secundum necessitates machinae. In AL designatio aeris lubricator permittit ad integrationem instrumenti praeparationis aeris addito SMC type.

AL lubricator Definitiones Communia

Probatur pressura	1.5 Mpa (15.3 kgf/cm2)
Maxime operantes pressura	1.0Mpa(10.2 kgf/cm²）
Ambiens et fluida temperaturis	5-60℃
Apertura filtationis	5 μm
Commendatur oleum	ISOVG 32
Poculum materiale	PC
Calicem tutela operimentum	AL1000-2000 (sine) AL 3000-5000 (cum)

ITEM.	Minimum operating rate fluxus (L/min)	L/min	Rc (PT)	cm²	Kg
AL1000-M5	4	95	M5X8	7	0.07
AL2000-02	15	800	1/4.	25	0.22
AL3000-02	30	1700	1/4.	50	0.3
AL3000-03	40	5000	3/8.	50	0.3
AL4000-03	40	5000	3/8.	130	0.56
AL4000-04	50	5000	1/2.	130	0.56
AL4000-06	50	6300	3/4.	130	0.58
AL5000-06	190	7000	3/4.	130	1.08
AL5000-10	190	7000	1	130	1.08
